Automatic Paint Mixer/Paint Mixer Disperser/Paint Stirrer Mixer

Automatic paint mixing machine/paint mixing disperser/paint agitator mixerBrand: L&BMaterial : stainless steel 304(L) 316(L)Finish: Mirror or Matt Polish; Ra<0.8umCertification: CE  ISO9001:2000Product Name:Automatic paint mixing machine/paint mixing disperser/paint agitator mixerDescription:Designed according t

Featured Products

Automatic paint mixing machine/paint mixing disperser/paint agitator mixer

Brand: L&B

Material : stainless steel 304(L) 316(L)

Finish: Mirror or Matt Polish; Ra<0.8um

Certification: CE  ISO9001:2000

Product Name:

Automatic paint mixing machine/paint mixing disperser/paint agitator mixer

Description:

Designed according to GMP standard, widely used for mixing liquid mediumin the food-processing, cosmetics and pharmaceutical industries

Heating method

By electricity (oils or water), by steam, by gas or no heating

Material:

SS304/SS316L

jacket: dimple jacket/ miller board, hollow jacket or coil pipe jacket etc.

insulation layer: PU Foam

as to the thickness, we can make it according to your requirement.

OptionalConfiguration

1.manhole

2.CIP spraying ball

3.adjusting feet

4.sample valve

5.temperature gauge

6.pressure gauge

7.level gauge

Capacity:

50L-10000L

Agitator:

With agitator or not

Agitator type

Frame, paddle, scraper, homogenizer, turbo type etc.

Agitator Speed

20-36rpm, 50-300rpm, 760-1450rpm, 2800-3000rpm

Mechanical seal:

SIC/SiC/EPDM(Standard)

Agitator power:

0.55kw, 1.1kw, 1.5kw, 2.2kw, 3kw, …7.5KW

Sealing option:

Sanitary single mechanical seal/Double mechanical seal with cooling system

Voltage:

110-480V, 50/60Hz

Motor:

ABB, LOCAL,50hz/ 60hz

Surface treatment:

Inner polished and outside polished

Available connection:

Clamp, Thread Butt weld, Flange

Available standard:

DIN, SMS, 3A, RJT, ISO/IDF

Operated:

Electric

Application scope:

Dairy, food, beverage, pharmacy, cosmetic, etc

Packaging Details:

Plywood case Or as per the request of customers

Delivery details:

Usually within 35 days after receiving T/T down payment


Technical parameters of Automatic paint mixing machine/paint mixing disperser/paint agitator mixer:
Effective volume (L)Dimension of tank (mm*mm)Total height (mm)Heat preservation layer (mm)Diameter of inlet&outlet (mm)
500840*100027506038
600920*100028506038
700990*100028506038
800950*122030006038
9001010*122030006038
10001060*122031506051
15001160*150033506051
20001340*150034106051
30001410*200040006051
40001620*200042506051
50001810*200043006051
60001980*200045506051
70001930*244050006051
80002060*244050006051
90002180*244050506051
100002300*244050506051
120002270*300056006051
150002530*300057006051
200002640*366064006051
